VSP 40 G Submersible Drainage Pump

Description

VSP 40 G Submersible Drainage Pump with float Switch INSTALLATION & USE Plastic, drainage, submersible pumps with open impeller, equipped with a float switch for automatic operation. The VSP40G submersible drainage pump is suitable for domestic use. Drainage pump for emptying pits and cisterns, for gardening; completely constructed in anti-corrosive material. CONSTRUCTION Pump body – Polypropylene Impeller – Noryl Mechanical seal – Double lip seal Motor Shaft – Stainless steel AISI 416 with ceramic bush Cable – H07 RNF, 10m G – Float switch 2 pole induction motor – 1~ 230V-50Hz with thermal protection Insulation class – F Protection degree – IP68 PERFORMANCE RANGE Flow rate up to: 80 l/min (4.8 m³/h) Head up to: 6m APPLICATION LIMITS Passage of suspended solids – Ø max 4 mm Depth of immersion – max 5m Liquid temperature – 0-40 °C
