Pedrollo TOP Multi Submersible Well Pump TOP MULTI 2 Manual (Without Float)

Description

Pedrollo TOP Multi Submersible Well Pump INSTALLATION & USE The Pedrollo TOP MULTI submersible pumps are suitable for use in applications such as domestic water supply from reservoirs, tanks or relatively deep wells, for drawing rain water from cisterns to water gardens or for use in irrigation systems, etc as a result of their high efficiency and reliability. Designed for simple installation and flexible use in gardening, cellar drainage and emptying and filling of deep wells. Combine the Pedrollo Top Multi with a Brio controller and a 2lt expansion vessel to create an automatic well water pumping kit. Supplied with 10 meters of electrical cable. CONSTRUCTION Glass fibre reinforced technopolymer , complete with threaded ports in compliance with ISO 228/1 Glass fibre reinforced technopolymer pump body and suction filter Stainless steel AISI 304 motor sleeve Noryl Noryl FE1520PW impellers Noryl diffusers complete with anti-wear rings Stainless steel motor shaft EN 10088-3 – 1.4104 Power Supply:  230V Single Phase (230/1/50) Ports: 1″ 1/4 Power: 0.75kW Complete with: – 10 m long power cable – float switch – hose connector Ø 35 mm – complete connector with flap-check valve PERFORMANCE RANGE Flow rate up to  120l/min (7.2 m³/h) Head up to 42m APPLICATION LIMITS – 10 m maximum immersion depth (with a sufficiently long power cable) – Maximum liquid temperature 40 °C – Suction down to 35 mm above ground level – Continuous service S1
