Pedrollo PRO-NGA Stainless Steel Centrifugal Pumps with Open Impeller NGA1A-PRO Single Phase

Description

Pedrollo PRO-NGA Stainless Steel Centrifugal Pumps with Open Impeller INSTALLATION & USE The Pedrollo NGA-PRO Centrifugal Pumps are suitable for use with liquids that are not chemically aggressive towards the materials from which the pump is made. The open impeller design allows liquids containing relatively high levels of impurities to be pumped without the risk of the impeller clogging. All of the components in contact with the pumped liquid are constructed in stainless steel AISI 316. Because of this characteristic the NGA-PRO series of pumps are particularly suitable for use in plants for washing fruit, vegetables, fish and shellfish, in industrial washing plants and for the circulation of cooling liquids We always recommend getting pumps installed by a qualified plumber. The pump should be installed in an enclosed environment or sheltered from inclement weather. CONSTRUCTION Models: Pedrollo NGA1B-PRO | NGA1A-PRO Pump Body: Stainless Steel AISI 316 , complete with threaded ports in compliance with ISO 228/1 Body Back Plate: Stainless Steel AISI 316 Impeller: Open Impeller in Stainless Steel 316 Motor Shaft: Stainless steel AISI 316 Power Supply:  230V Single Phase (230/1/50) or 400V Three Phase (400/3/50) Ports – Inlet & Outlet: 1’1/2″ BSP Female PERFORMANCE RANGE Flow rate up to  350l/min (21 m³/h) Head up to 20m APPLICATION LIMITS – Manometric suction lift up to 7m – Liquid temperatures between -10°C and 90°C – Ambient temperature between -10°C and 40°C – Max working pressure 6 bar – Passage of suspended solids up to Ø 10 mm
