Marco VP45-K 12V/24V Refuelling Kit with Vane Pump VP45K 12v

Description

Marco VP45-K 12V/24V Refuelling Kit with Vane Pump INSTALLATION & USE Kit for diesel refuelling. Includes the vane pump with integrated by-pass valve and battery clips. Refueling gun, 2 m priming hose, 3 m delivery hose and intake filter. There are numerous fields of applications for the pump, however only exclusively with the allowed liquids mentioned: – transfer of diesel fuel between tanks, refueling of tractors and earth moving equipment – transfer of water – transfer of antifreeze, etc. CONSTRUCTION Code: 16602412 (12V) or 16602413 (24V) Volt: 12 or 24V Consumption: 8A (12V model) 4A (24V model) Fuse: 20A / 10A Weight: 6.3kg Dimensions 210x120x166 mm Hose 25mm Max self priming to 1.5 meter Ports: 3/4″ BSP PERFORMANCE RANGE Max Flow Rate: 45 l/min Max Pressure: 1.2 Bar APPLICATION LIMITS Temperature: Min -10°C / max 60°C Relative Humidity: max. 90°C Fluids Allowed / Not Allowed: Allowed: Fresh Water Allowed: Diesel – Minimum flash point (PM): 55°C – 131°F NOT Allowed: Petrol (Gasoline) NOT Allowed: Flammable Liquids with PM 20 cSt NOT Allowed: Foodstuff Liquids NOT Allowed: Corrosive Chemical Products NOT Allowed: Solvents
