Marco OCK1-E Reversible Oil/Diesel Transfer Kit

Description

Marco OCK1-E Reversible Oil/Diesel Transfer Kit INSTALLATION & USE Compact size oil transfer kit. Easy to operate and carry. Reversible: draws and fills oil. Complete with bronze gear pump, clips, fuse, hoses and accessories for transferring operations. Available also with electronic control panel and 12/24V universal voltage. Self-priming electric pump designed for lubricants and viscous fluids. The pumping elements are made up of bronze gear drives which can possibly even run dry for brief periods. Equipped with a fast connector for oil suction pipe. There are numerous fields of applications for the pump, however only exclusively with the allowed liquids mentioned: Transfer of lubricating oil Transfer of viscous liquids Transfer of oils, antifreeze Circulation of viscous liquids Draining of engine sumps CONSTRUCTION Code: 16493115 (12V/24V) Volt: 12/24V Consumption: 6A (12V) 3A (24V) Fuse: 7.5A Weight: 2.4kg Motor Power: 120W Dimensions 139x108x86 mm Ports: 3/8″ BSP Max self priming to 1 meter PERFORMANCE RANGE Max Flow Rate: 15 l/min Max Pressure: 2 Bar (29psi) APPLICATION LIMITS Temperature: Min -10°C / max 60°C Relative Humidity: max. 90°C Fluids Allowed / Not Allowed: Allowed: Motor Oil (max 120°C°C-248°F) max viscosity 350 cSt Allowed: Diesel – Minimum flash point (PM): 55°C – 131°F NOT Allowed: Petrol (Gasoline) NOT Allowed: Flammable Liquids with PM <100°F NOT Allowed: Foodstuff Liquids NOT Allowed: Corrosive Chemical Products NOT Allowed: Solvents
